- 30Ml PUR Automatic Dispensing Machine
-
Product Number：DJ331ZM/DJ551ZM
Product Brand：PINSU
Product Description：
- +86-400-7788-990
- Product Parameters
- Application Industry
- App Video
30Ml PUR Automatic Dispensing Machine is mainly used for dispensing PUR hot melt adhesive in 30ml syringes, mainly composed of dispenser table, hot melt dispensing valve and temperature controller, air filter.
【Machine Parameter】
|
Machine name |
30Ml PUR Automatic Dispensing Machine |
|
|
Machine model |
PS-DJ331ZM |
PS-DJ551ZMR |
|
Effective stroke（X/Y/Z） |
30*30*10CM |
50*50*10CM |
|
Machine size |
58.5*53.0*58.6 |
70.5*53.0*58.6 |
|
Machine weight |
50KG |
70KG |
|
Maximum load of synchronous belt |
X/Y-axis 5kg, Z-axis 3kg |
|
|
Maximum load of lead screw |
X/Y-axis 15kg, Z-axis 10kg |
|
|
Electronic control system |
Intelligent motion control card (with teaching box) |
|
|
Information storage space |
256MB |
|
|
Supported Project Documents |
CAD/ corelDRAW |
|
|
Operation mode |
The stepper motor drives the belt or servo motor driven lead screw |
|
|
Operation track |
Points, lines, circles, arcs, rectangles, S-shapes, etc |
|
|
Operation speed |
Max 300mm/s |
|
|
Repeatability |
±0.05mm-±0.02mm |
|
|
Power supply |
AC 110V/60HZ，AC 220V/50HZ |
|
|
Machine Power |
400W |
|
|
Operating pressure range |
0.5-0.8MPa |
|
【Machine Feature 】
1. Simple operation, easy to learn and understand, high speed and precision;
2, can point, line, arc, circle, irregular curve continuous dispensing;
3, support for arrays, three-dimensional ellipse, commonly used graphics library insertion, group editing and other advanced features;
4, can be adjusted at will when the dispensing trajectory, storage of multiple dispensing trajectory of the file, without repeated editing;
5, the size of the amount of glue, glue speed, dispensing time, stopping time can be parameterized;
6, with a special dispensing controller, the amount of glue is stable, clean breaks, no leakage of glue;
7, with automatic anti-curing function, effectively prevent the glue curing blocking the needle;
8, the key components are carefully selected parts, in order to ensure high speed, precision at the same time, to meet the requirements of high reliability under automated production conditions.
【Applicable Glue】
30Ml PUR Automatic Dispensing Machine for PUR hot melt adhesive in 30ml syringes
【Scope of Application】
30Ml PUR Automatic Dispensing Machine are used in Electronics, Electrical Appliances, Digital Machines, Lighting, Switches, Power Supplies.
